    150mm Extended Length Lockable Gas Spring Lift Support 500n For Train Or Bus Seat

    Ask Lasest Price
    Brand Name : CSZIY
    Model Number : KQ150-500N
    Certification : ISO9001
    Price : USD3.6/PCS~USD5/PCS
    Payment Terms : D/A, L/C, D/P, T/T, , MoneyGram,PAYPAL
    Supply Ability : 4000PCS PER DAY
    Delivery Time : 4-7 WORKING DAYS
    • Product Details
    • Company Profile

    150mm Extended Length Lockable Gas Spring Lift Support 500n For Train Or Bus Seat

    lockable gas spring lift 500n for train or bus seat

    Description:

    Extended length:120mm

    stroke length:30mm

    tube diameter:28mm

    rod diameter:10mm

    force:500n


    A special variation of this locking gas spring comes with an additional override function. This function, designed for special customer requests, is to protect the application from overload.

    The override function is available in the tension or compression direction.

    lockable gas spring lift 500n for train or bus seat

    Stroke Hub

    Extended length

    Force F1 [N]

    20


    149,5

    300

    350

    400

    500

    600

    800

    1000

    1200

    25

    157,5

    250

    300

    350

    400

    500

    600

    800

    1000

    1200

    D1 [mm]

    D2 [mm]

    Force of extension F1 [N]

    FR max. [N]

    10

    22

    200 - 1000

    80

    10

    28

    200 - 1200

    80

    lockable gas spring lift 500n for train or bus seat
    All goods can be customized .
    Please feel free to contact us for more detailed information .

    The Auto Gas Springs can be customized according to your requirements:Force ,Stroke,Thread diameter.Please contact us freely if you need to order.

    Please contact us for detail!


    Mainly Specifications:

    Extended length(mm)stroke length(mm)D1*D2(MM)Force F1(N)Fr(max)
    100~30030~1004*1220~20030
    301~600101~2006*1550~20050
    601~900201~3008*18100~80060
    901~1200301~40010*22150~115080
    1201~1600401~50012*22150~120080
    500~1200200~50012*26200~150080
    500~1300200~60012*28200~2000100

    more questions as following:

    Q1. What is your terms of packing?
    A: Generally, we pack our goods in neutral brown boxes and brown cartons. If you have legally registered patent,
    we can pack the goods in your branded boxes after getting your authorization letters.

    Q2. What is your terms of payment?
    A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
    before you pay the balance.

    Q3. What is your terms of delivery?
    A: EXW, FOB, CFR, CIF, DDU.

    Q4. How about your delivery time?
    A: Generally, it will take 7 to 15 days after receiving your advance payment. The specific delivery time depends
    on the items and the quantity of your order.

    Q5. Can you produce according to the samples?
    A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

    Q6. What is your sample policy?
    A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
    the courier cost.

    Q7. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery

    Q8: How do you make our business long-term and good relationship?
    A:1. We keep good quality and competitive price to ensure our customers benefit ;
    2. We respect every customer as our friend and we sincerely do business and make friends with them,
    no matter where they come from.


    Thank you for your visting, please feel free to contact us for more detailed information.
